| Weight | 150 lbs |
|---|---|
| Note |
We have a variety of muffler applications available |
| Fits |
This engine is ready to power your ZTR, wide-area walk-behind mower, or lawn tractor. |
| Replaces |
*Used on Toro, Exmark, Scag, Bad Boy, KMC, Ariens, Excel, MTD, Dixie Chopper, and many others. |
Kawasaki FX600V Engine
$1,595.00
FX600V 15.0 hp The FX600V engine puts the extra push you need for heavy lawn care needs. This 90° V-twin engine features high performance pressurized lubrication and an internally vented carburetor.
Specifications
Engine Style Vertical Cylinders 2
Engine Type 4-Cycle OHV
Cooling System Air Dry
Weight 89.7 Lbs
CC 603 CCs
HP 19 HP
Max Torque 32.5 ft-lbs
Cylinder Bore Type Cast Iron
Bore 2.9 Inches
Stroke 2.8 Inches
Compression Ratio 8.1:1
Starting System 12-Volt (No Key)
Ignition System Electronic Spark
Lubrication Pressurized
Oil Filter Yes
Oil Capacity 57.6 oz
Fuel Gas
Carburetor Float
Manifold and muffler Included
Air Cleaner, Multi-Stage Canister
Fuel Tank Not Included
Crankshaft Rotation Direction Counterclockwise
Shaft Size 1 x 3-5/32 Inch
Crankshaft Type Straight
Crankshaft Diameter 1″
Crankshaft Length 3-5/32″
Made in USA Yes
Consumer Warranty 3 Years
Commercial Warranty 3 Years
Features
FX600V-_S00S – 1″ x 80mm Crankshaft,12V Start, Chrg Coil, Separate C & T Controls 1″ x 80mm Crankshaft For Zero-turn riders, lawn tractors & wide-area walk behind mowers Kawasaki FX600V Series Air-Cooled OHV V-Twin Critical Power Engine SAE Certified for consistent, accurate horsepower; Produces 19 HP @3600 RPM 90° V-Twin Cylinder Engineering Smooth, well-balanced power output in a compact package Cast Iron cyclinder liners provide increased protection & longevity Overhead V-Valve (OHV) Technology For maximum power, quiet operation & ensures low emissions Pressurized Lubrication System w/ Spin-On Oil Filter Multi-stage canister Air Filtration System for more air-particle removal Two-Channel Forced Air-Cooling & Rotating Grass Screen Prevents overheating while boosting efficiency on even those HOT days Electronic Spark Ignition & 12V Electric Starter (Cables Not Included) Auto-Compression realease plus an Internally-vented carbuerator for reliable, consistent starting Also Includes Separate Choke & Throttle Control; Charging Coil Designed to easily integrate with your current mower 50-State CARB Compliant
